87165-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 22-26AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.72424
≥100 USD $0.596552
≥500 USD $0.468943
≥1000 USD $0.401949
≥3000 USD $0.394812
Inventory: 837
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 100.0μin 2.54μm
Length 15.03mm
Height 2.97mm
Technical
Cable Entry-Min 0.038 inch
Cable Entry-Max 0.062 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Contact Design LOOSE
Insulation Diameter 1.5748 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 22 AWG
Connector Support Type CONNECTOR ACCESSORY
ELV Non-Compliant
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Contact Resistance 16mOhm
Contact Style Clip
Approval Agency UL
Contact Finish Tin-Lead
Current Rating 3A
Reach Compliance Code not_compliant
Depth 2.92mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 750V
Gender Female
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU
Published 1997
Packaging Bulk
Physical
Contact Shape Square
Mount Cable
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 24 Weeks
