86492-9 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKET 20-24AWG TIN CRIMP
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2904
≥1 USD $0.2904
≥10 USD $0.2728
≥100 USD $0.271392
≥500 USD $0.264528
≥1000 USD $0.226864
≥3000 USD $0.205181
Inventory: 67395
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Contact Finish Thickness 78.0μin 1.98μm
Length 12.24mm
Height 2.03mm

Technical

Pin or Socket Socket
Wire Cross Section 0.6 mm2
Insulation Diameter 1.75 mm
Contact Termination Crimp
Terminal and Terminal Block Type WIRE TERMINAL
Contact Current Rating 3A
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 24 AWG
Wire/Cable Type Discrete
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 20-24 AWG
Contact Resistance 12mOhm
Operating Supply Voltage 250V
Contact Gender Female
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Tin
Current Rating 3A
Depth 2.41mm
Shielding Unshielded
Orientation Straight
HTS Code 8536.90.40.00
Gender Receptacle
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod IV 1/2
Published 2000
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 14 Weeks
