86492-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 24-20AWG 30GOLD
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264986
≥1 USD $0.264986
≥10 USD $0.249991
≥100 USD $0.235839
≥500 USD $0.22249
≥1000 USD $0.209893
Inventory: 6314
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 12.24mm
Height 2.03mm
Technical
Design Use POWER AND SIGNAL
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 1.75 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 24 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 20-24 AWG
Contact Resistance 12mOhm
Operating Supply Voltage 250V
Contact Gender Female
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Gold
Current Rating 3A
Depth 2.41mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Receptacle
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPMODU Mod IV 1/2
Published 2008
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 14 Weeks
