794956-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKT 18-22AWG PHOS BRZ TIN
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.0396
≥100 USD $0.036608
≥500 USD $0.034672
≥1000 USD $0.032736
≥3000 USD $0.030518
Inventory: 72156
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Finish Thickness 100
Plating Thickness 2.54μm
Length 14.55mm
Height 4.5mm

Technical

Cable Entry-Min 0.059 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 3.1 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 9A
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire/Cable Type Discrete
Max Current Rating 9A
ELV Compliant
Wire Gauge 18-22 AWG
Operating Supply Voltage 600V
Contact Gender Female
Approval Agency UL
Contact Finish Tin
Current Rating 9A
Depth 3.7mm
Shielding Unshielded
Orientation Straight
Pitch 4.2mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series VAL-U-LOK
Published 2008
Packaging Tape & Reel (TR)

Physical

Number of Pins 1
Mount Cable
Contact Material Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 16 Weeks
