794955-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN PIN 18-22AWG BRASS TIN
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.02464
≥100 USD $0.022528
≥500 USD $0.021472
≥1000 USD $0.020328
≥3000 USD $0.018902
Inventory: 822654
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Finish Thickness 100
Plating Thickness 2.54μm
Length 16.8mm
Height 4.5mm

Technical

Cable Entry-Min 0.059 inch
Wire Size (Min) 24 AWG
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 3.1 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 9A
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 9A
ELV Compliant
Wire Gauge 18-22 AWG
Operating Supply Voltage 600V
Contact Gender Male
Approval Agency UL
Contact Finish Tin
Current Rating 9A
Depth 3.7mm
Orientation Straight
Pitch 2.54mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 600V
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Number of Positions 36
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series VAL-U-LOK
Published 2000
Packaging Tape & Reel (TR)

Physical

Material Brass
Number of Pins 1
Mount Cable

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 21 Weeks
