794230-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN PIN 16-20AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
≥10 USD $0.3036
≥100 USD $0.302016
≥500 USD $0.294448
≥1000 USD $0.25256
≥3000 USD $0.228483
Inventory: 7758
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Contact Material Brass
Mount Cable

Technical

Packaging Bulk
Published 2005
Series Mini-Universal MATE-N-LOK II
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 1
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Voltage - Rated 600V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 4.45mm
Current Rating 9.5A
Contact Finish Tin
Approval Agency UL
Contact Gender Male
Operating Supply Voltage 600V
Wire Gauge 16-20 AWG
ELV Compliant
Max Current Rating 10.5A
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 20 AWG
Wire/Cable Gauge 16 AWG
Contact Current Rating 10.5A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 3.2 mm
Pin or Socket Pin
Assembly Item Name CONTACT
VDE Tested Yes
Cable Entry-Min 0.079 inch

Dimensions

Height 3.94mm
Length 20.2mm

Compliance

REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
