794229-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 18-22AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.484
≥1 USD $0.484
≥10 USD $0.46728
≥100 USD $0.465696
≥500 USD $0.449856
≥1000 USD $0.377168
≥3000 USD $0.353619
Inventory: 6271
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Brass
Contact Plating Gold
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2008
Series Mini-Universal MATE-N-LOK II
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Socket
Max Operating Temperature 105°C
Min Operating Temperature -20°C
Voltage - Rated 600V
Orientation Straight
Depth 3.81mm
Current Rating 10.5A
Contact Finish Gold
Approval Agency UL
Contact Gender Female
Operating Supply Voltage 600V
Contact Resistance 20mOhm
Wire Gauge 18-22 AWG
ELV Non-Compliant
Max Current Rating 10.5A
Plating Gold
Wire/Cable Type Discrete
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 18 AWG
Wire/Cable Gauge 18 AWG
Contact Current Rating 10.5A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 2.794 mm
Pin or Socket Socket
VDE Tested Yes
Dimensions
Height 4.42mm
Length 20.2mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 2.54μm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Not Applicable
