794216-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Contact PIN Crimp ST Cable Mount Strip
PDF
/
Buying Options
Total Price: USD $0.01
Unit Price: USD $0.014877
≥1 USD $0.014877
≥200 USD $0.005757
≥500 USD $0.005555
≥1000 USD $0.005455
Inventory: 3144
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Length 20.2mm
Technical
VDE Tested Yes
Pin or Socket Pin
Insulation Diameter 1.27 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 10.5A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 30 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 10.5A
ELV Compliant
Wire Gauge 26-30 AWG
Contact Resistance 20mOhm
Operating Supply Voltage 600V
Approval Agency UL
Contact Finish Tin
Current Rating 9.5A
Depth 2.67mm
Orientation Straight
Gender Male
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Mini-Universal MATE-N-LOK II
Published 2005
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 10 Weeks
