794001-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKET 24-26AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.3432
≥100 USD $0.286088
≥500 USD $0.213145
≥1000 USD $0.190256
≥3000 USD $0.177047
Inventory: 2879
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Plating Thickness 380 nm
Length 16.76mm

Technical

Pin or Socket Socket
Insulation Diameter 1.27 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 9A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Discrete
Max Current Rating 9A
ELV Compliant
Wire Gauge 24-26 AWG
Contact Resistance 5mOhm
Operating Supply Voltage 250V
Contact Gender Female
Contact Finish Tin
Current Rating 19A
Depth 2.29mm
Orientation Straight
Voltage - Rated 600V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series MR (Miniature Rectangular)
Published 1997
Packaging Bulk

Physical

Housing Material Nylon
Mount Cable
Contact Material Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 7 Weeks
