794000-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 26-24AWG TIN
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.23056
≥100 USD $0.229504
≥500 USD $0.226512
≥1000 USD $0.209264
≥3000 USD $0.171987
Inventory: 6507
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Bronze
Mount Cable
Technical
Packaging Tape & Reel (TR)
Published 1997
Series MR (Miniature Rectangular)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 1
Max Operating Temperature 221°C
Min Operating Temperature -40°C
Voltage - Rated 250V
Orientation Straight
Depth 2.57mm
Current Rating 9A
Contact Finish Tin
Contact Gender Female
Operating Supply Voltage 250V
Contact Resistance 5mOhm
Wire Gauge 24-26 AWG
ELV Compliant
Max Current Rating 9A
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 24 AWG
Contact Current Rating 9A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 1.27 mm
Pin or Socket Socket
Dimensions
Length 16.76mm
Plating Thickness 400 nm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
