776492-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 14-18AWG TIN
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.1088
≥1 USD $1.1088
≥10 USD $1.03664
≥100 USD $0.99792
≥500 USD $0.988416
≥1000 USD $0.89188
≥3000 USD $0.862963
Inventory: 7114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Cable
Material Tin
Technical
Packaging Tape & Reel (TR)
Published 2009
Series AMPSEAL 16 HDSF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Connector, Crimp, Power, Signal, Socket
Type Stamped
Number of Positions 18
Max Operating Temperature 248°C
Min Operating Temperature -40°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 4.14mm
Orientation Straight
Shielding Unshielded
Depth 4.44mm
Current Rating 13A
Contact Gender Female
Wire Gauge 14-18 AWG
ELV Compliant
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 18 AWG
Sealable No
Contact Termination Crimp
Insulation Diameter 3.32 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Cable Entry-Max 0.131 inch
Cable Entry-Min 0.089 inch
Dimensions
Height 4.31mm
Length 21.59mm
Contact Finish Thickness 100.0μin 2.54μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
