770672-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 26-30AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.17776
≥100 USD $0.16192
≥500 USD $0.116794
≥1000 USD $0.103488
≥3000 USD $0.091661
Inventory: 3117
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Length 25.65mm
Height 2.05mm
Technical
Cable Entry-Min 0.032 inch
Cable Entry-Max 0.057 inch
VDE Tested Yes
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 1.4478 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 19A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 30 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 19A
ELV Compliant
Wire Gauge 26-30 AWG
Contact Resistance 1Ohm
Operating Supply Voltage 600V
Contact Gender Male
Approval Agency UL
Contact Finish Tin
Current Rating 19A
Depth 2.05mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK
Published 1997
Packaging Bulk
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 19 Weeks
