770642-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
TIMER CONN TERM,REAR CARRIER
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
≥10 USD $0.11616
≥100 USD $0.108064
≥500 USD $0.102432
≥1000 USD $0.096888
≥3000 USD $0.090182
Inventory: 1200
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tab Thickness 510μm
Contact Finish Thickness 130.0μin 3.30μm
Length 16.89mm
Height 5.72mm
Technical
Insulated Wire Support Yes
Mating Tab Width 3.18mm
Pin or Socket Socket
Wire Cross Section 2 mm2
Wire/Cable Diameter 3.1242 mm
Insulation Non-Insulated
Insulation Diameter 3.1242 mm
Contact Termination Crimp
Terminal and Terminal Block Type PUSH-ON TERMINAL
Sealable No
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 14-20 AWG
Contact Resistance 4mOhm
Contact Finish Tin
Depth 5.08mm
Shielding Unshielded
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, PCB, Signal, Socket
ECCN Code EAR99
Termination Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Standard Timer
Published 1999
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
