770522-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 18-24AWG CRIMP TIN
PDF
/
Inventory: 1306
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2006
Series SL-156
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Power
Number of Positions 8
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Gender Receptacle
Pitch 3.96mm
Orientation Straight
Shielding Unshielded
Depth 3.94mm
Contact Finish Tin-Lead
Number of Contacts 1
Contact Gender Female
Contact Style Standard
Contact Resistance 3mOhm
Wire Gauge 18-24 AWG
ELV Non-Compliant
Max Voltage Rating (AC) 250V
Wire/Cable Type Discrete
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 18 AWG
Wire/Cable Gauge 24 AWG
Contact Current Rating 10A
Contact Termination Crimp
Insulation Diameter 2.794 mm
Pin or Socket Socket
Dimensions
Height 4.45mm
Contact Finish Thickness 80.0μin 2.03μm
Plating Thickness 2.03μm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
