770211-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Pin & Socket Connectors UMNL SOK CONT PTPBR
PDF
/
Inventory: 9154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Length 19.3mm
Technical
Cable Entry-Min 0.06 inch
Cable Entry-Max 0.13 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Contact Retention With
Contact Termination Crimp
Circuit Application Power
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 24 AWG
Cable Type DISCRETE WIRE
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Wire Gauge 18-24 AWG
Operating Supply Voltage 600V
Operating Temperature (Min) -55°C
Contact Gender Female
Operating Temperature (Max) 125°C
Approval Agency CSA; UL; VDE
Contact Finish Tin
Current Rating 19A
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK
Published 1999
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 17 Weeks
