770193-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 14-20AWG TIN CRIMP TERM
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.1848
≥1 USD $0.1848
≥10 USD $0.15664
≥100 USD $0.156288
≥500 USD $0.154352
≥1000 USD $0.14256
≥3000 USD $0.117181
Inventory: 45022
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 28.07mm
Technical
Cable Entry-Min 0.06 inch
Cable Entry-Max 0.13 inch
VDE Tested Yes
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 3.302 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 7A
Wire/Cable Gauge 14 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 14 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 7A
ELV Compliant
Wire Gauge 14-20 AWG
Operating Supply Voltage 600V
Contact Gender Male
Approval Agency UL
Contact Finish Tin
Current Rating 19A
Depth 4.19mm
Orientation Straight
Pitch 250μm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -55°C
Max Operating Temperature 120°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK II
Published 2008
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 14 Weeks
