770005-4 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Pin & Socket Connectors 20-14 AWG PIN
PDF
/
Inventory: 4895
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status Non-RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 25.27mm
Height 5.97mm

Technical

Rated Voltage(AC) 600V
Cable Entry-Max 0.2 inch
Assembly Item Name CONTACT
Pin or Socket Split Pin
Contact Termination Crimp
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 20 AWG
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 19A
ELV Non-Compliant
Wire Gauge 14-20 AWG
Contact Resistance 10mOhm
Contact Gender MALE
Contact Finish Gold
Current Rating 19A
Depth 5.97mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 1
Connector Type Pin
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series Universal MATE-N-LOK II
Published 2008
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Material Bronze

Supply Chain

Factory Lead Time 23 Weeks
