647406-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Headers & Wire Housings SLD 156 RCPT AUNI/PHBZ LARG DIA
PDF
/
Inventory: 6687
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free

Dimensions

Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 13.3mm

Technical

Pin or Socket Socket
Insulation Diameter 2.84 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 10A
Sealable No
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 24 AWG
Wire/Cable Type Discrete
Plating Gold
ELV Compliant
Wire Gauge 18-24 AWG
Contact Style Standard
Operating Supply Voltage 250V
Contact Finish Gold
Current Rating 10A
Shielding Unshielded
Orientation Straight
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Type Power
Connector Type Socket
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SL-156
Published 2008
Packaging Tape & Reel (TR)

Physical

Underplate Material Nickel
Mount Cable
Contact Plating Gold
Contact Material Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 17 Weeks
