641294-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 18-26AWG TIN CRIMP
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.19096
≥100 USD $0.19008
≥500 USD $0.187792
≥1000 USD $0.173536
≥3000 USD $0.142595
Inventory: 34217
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Bronze
Mount Cable
Technical
Packaging Tape & Reel (TR)
Published 1999
Series MR (Miniature Rectangular)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 1
Max Operating Temperature 185°C
Min Operating Temperature -67°C
Voltage - Rated 250V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 3.96mm
Orientation Straight
Shielding Unshielded
Depth 3.68mm
Current Rating 9A
Contact Finish Tin
Contact Gender Female
Operating Supply Voltage 250V
Contact Resistance 5mOhm
Wire Gauge 18-26 AWG
ELV Compliant
Max Current Rating 9A
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 18 AWG
Wire/Cable Gauge 26 AWG
Contact Current Rating 9A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 2.921 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Cable Entry-Min 0.05 inch
Dimensions
Height 3.48mm
Length 16.76mm
Plating Thickness 400 nm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
