640706-1 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKET 18-24AWG CRIMP TIN
PDF
/
Inventory: 1172
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Brass
Contact Plating Lead, Tin
Mount Cable
Underplate Material Nickel

Technical

Packaging Bulk
Published 1997
Series SL-156
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Power
Max Operating Temperature 221°C
Min Operating Temperature -67°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 3.56mm
Contact Finish Tin-Lead
Number of Contacts 1
Contact Gender Female
Contact Style Standard
Contact Resistance 3mOhm
Wire Gauge 18-24 AWG
Wire/Cable Type Discrete
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 18 AWG
Wire/Cable Gauge 24 AWG
Contact Current Rating 6.5A
Contact Termination Crimp
Insulation Diameter 2.794 mm
Pin or Socket Socket
Assembly Item Name CONTACT

Dimensions

Contact Finish Thickness 80.0μin 2.03μm
Plating Thickness 2.03μm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
