640347-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 18-24AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.9768
≥1 USD $0.9768
≥10 USD $0.91168
≥100 USD $0.877888
≥500 USD $0.869264
≥1000 USD $0.78452
≥3000 USD $0.759053
Inventory: 14459
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Brass
Contact Plating Gold, Nickel
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2005
Series Universal MATE-N-LOK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Voltage - Rated 600V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Depth 3.7mm
Current Rating 19A
Contact Finish Gold
Approval Agency UL
Contact Gender Female
Operating Supply Voltage 600V
Contact Style RND PIN-SKT
Wire Gauge 18-24 AWG
ELV Compliant
Max Voltage Rating (AC) 600V
Max Current Rating 19A
Plating Gold, Nickel
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 24 AWG
Wire/Cable Gauge 18 AWG
Contact Current Rating 19A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 2.54 mm
Pin or Socket Socket
Assembly Item Name CONTACT
VDE Tested Yes
Cable Entry-Min 0.04 inch
Dimensions
Height 3.7mm
Length 19.3mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 1.27μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
