61603-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Heavy Duty Power Connectors TIMER TERM 20-14
PDF
/
Inventory: 5056
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Brass
Technical
Packaging Tape & Reel (TR)
Published 2006
Series Amplivar
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Receptacle
ECCN Code EAR99
Connector Type Connector, PCB, Signal
Max Operating Temperature 221°C
Min Operating Temperature -40°C
Gender Female
Voltage - Rated 300V
HTS Code 8536.90.40.00
Current Rating 11.5A
Wire Gauge 14-20 AWG
ELV Compliant
Plating Tin
Wire/Cable Type Discrete
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type PUSH-ON TERMINAL
Contact Termination Crimp
Insulation Diameter 3.175 mm
Insulation Non-Insulated
Wire/Cable Diameter 3.175 mm
Pin or Socket Socket
Mating Tab Width 3.18mm
Insulated Wire Support Yes
Dimensions
Length 12.827mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 400 nm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
