61314-5 image
Favorite
RoHS
RoHS RoHS compliant
Package 200
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKET 18-24AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.955513
≥1 USD $0.955513
≥10 USD $0.901432
≥100 USD $0.850401
≥500 USD $0.802267
≥1000 USD $0.756859
Inventory: 968
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 17.65mm
Height 3.81mm

Technical

Cable Entry-Max 0.1 inch
VDE Tested No
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.54 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 15A
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 24 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 15A
ELV Compliant
Wire Gauge 18-24 AWG
Operating Supply Voltage 250V
Contact Gender Female
Contact Finish Gold
Current Rating 13A
Depth 3.68mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Commercial MATE-N-LOK
Published 1997
Packaging Tape & Reel (TR)

Physical

Underplate Material Nickel
Package / Case 200
Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 14 Weeks
