61116-5 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN PIN 18-24 AWG 30GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $1.3
Unit Price: USD $1.3024
≥1 USD $1.3024
≥10 USD $1.188
≥100 USD $1.152448
≥500 USD $1.140832
≥1000 USD $1.058992
≥3000 USD $1.041427
Inventory: 31771
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 months ago)

Physical

Contact Material Brass
Mount Cable
Contact Shape Round
Underplate Material Nickel

Technical

Packaging Tape & Reel (TR)
Published 1997
Series Commercial MATE-N-LOK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Stamped
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Voltage - Rated 250V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 3.56mm
Current Rating 13A
Contact Finish Gold
Contact Gender Male
Operating Supply Voltage 250V
Wire Gauge 18-24 AWG
ELV Compliant
Max Voltage Rating (AC) 250V
Max Current Rating 15A
Wire/Cable Type Discrete
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 24 AWG
Wire/Cable Gauge 18 AWG
Contact Current Rating 15A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 2.54 mm
Pin or Socket Pin
Assembly Item Name CONTACT
VDE Tested No
Cable Entry-Max 0.1 inch

Dimensions

Height 3.35mm
Length 20.45mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 760 nm

Compliance

RoHS Status RoHS Compliant
Lead Free Not Applicable
