60620-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 14-20AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.22528
≥100 USD $0.224576
≥500 USD $0.221584
≥1000 USD $0.204776
≥3000 USD $0.168291
Inventory: 1256
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 20.447mm
Height 4.82mm
Technical
Used With CAP HOUSING
VDE Tested No
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 3.302 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 15A
Wire/Cable Gauge 14 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 15A
Max Voltage Rating (AC) 250V
ELV Compliant
Wire Gauge 14-20 AWG
Operating Supply Voltage 250V
Contact Gender Male
Number of Contacts 1
Approval Agency UL
Voltage - Rated AC 250V
Contact Finish Tin
Current Rating 13A
Depth 4.44mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Commercial MATE-N-LOK
Published 1997
Packaging Bulk
Physical
Contact Shape Round
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 14 Weeks
