531224-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Contact SKT Crimp ST Cable Mount Strip
PDF
/
Inventory: 9645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Contact Finish Gold
Approval Agency UL
Contact Gender Female
Contact Style BELLOWED TYPE
Contact Resistance 12mOhm
Wire Gauge 22-26 AWG
Insulation Resistance 5GOhm
ELV Non-Compliant
Connector Support Type CONNECTOR ACCESSORY
Cable Type WIRE, DISCRETE
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 26 AWG
Wire/Cable Gauge 26 AWG
Contact Current Rating 3A
Contact Termination Crimp
Insulation Diameter 1.37 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Make First / Break Last No
Design Use SIGNAL
Current Rating 3A
Depth 2.03mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 1kV
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU
Published 2007
Packaging Tape & Reel (TR)
Dimensions
Height 1.52mm
Length 13.2mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Not Applicable
Physical
PCB Mount Retention Without
Mount Cable
Contact Plating Tin, Gold
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 32 Weeks
