5-104505-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 22-26AWG 15GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2904
≥1 USD $0.2904
≥10 USD $0.26224
≥100 USD $0.261184
≥500 USD $0.255552
≥1000 USD $0.218416
≥3000 USD $0.196592
Inventory: 23331
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 20.62mm
Technical
Pin or Socket Pin
Insulation Diameter 1.37 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Plating Gold
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Contact Resistance 12mOhm
Contact Style Crimp
Operating Supply Voltage 300V
Approval Agency CSA
Voltage - Rated AC 300V
Contact Finish Gold
Current Rating 3A
Depth 1.9mm
Shielding Unshielded
Orientation Straight
Pitch 2.54mm
Gender Male
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Connector Type Pin
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU MTE
Published 2008
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Plating Gold, Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 months ago)
Factory Lead Time 6 Weeks
