350700-7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SPLIT PIN 20-14AWG U M-N-L
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.4224
≥100 USD $0.420288
≥500 USD $0.409728
≥1000 USD $0.351472
≥3000 USD $0.317962
Inventory: 8642
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Brass
Contact Plating Gold, Nickel
Mount Cable
Underplate Material Nickel
Technical
Packaging Tape & Reel (TR)
Published 1997
Series Universal MATE-N-LOK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Pin
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Voltage - Rated 600V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 6.1mm
Current Rating 19A
Contact Finish Gold
Approval Agency UL
Contact Gender Male
Operating Supply Voltage 600V
Wire Gauge 14-20 AWG
ELV Compliant
Max Current Rating 19A
Plating Gold, Nickel
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 14 AWG
Contact Current Rating 19A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 5.08 mm
Pin or Socket Split Pin
Assembly Item Name CONTACT
VDE Tested Yes
Cable Entry-Max 0.2 inch
Cable Entry-Min 0.13 inch
Dimensions
Height 6.1mm
Length 21.34mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 1.27μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
