350570-7 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKET 24-18AWG GOLD
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.42416
≥100 USD $0.422048
≥500 USD $0.411312
≥1000 USD $0.352792
≥3000 USD $0.319123
Inventory: 40953
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Plating Thickness 1.27μm
Contact Finish Thickness 30.0μin 0.76μm
Length 19.3mm
Height 3.55mm

Technical

Cable Entry-Min 0.04 inch
VDE Tested Yes
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.54 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 19A
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 18 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Plating Gold, Nickel
Max Current Rating 19A
Max Voltage Rating (AC) 600V
ELV Compliant
Wire Gauge 18-24 AWG
Operating Supply Voltage 600V
Contact Gender Female
Approval Agency UL
Contact Finish Gold
Current Rating 19A
Depth 4.19mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK
Published 1997
Packaging Tape & Reel (TR)

Physical

Underplate Material Nickel
Mount Cable
Contact Plating Gold, Nickel
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 10 Weeks
