350561-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 18-24AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.54032
≥100 USD $0.538208
≥500 USD $0.520256
≥1000 USD $0.436128
≥3000 USD $0.408883
Inventory: 38181
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 20.32mm
Height 3.68mm
Technical
VDE Tested Yes
Pin or Socket Pin
Insulation Diameter 2.54 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 19A
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 18 AWG
Number of Ports 1
Wire/Cable Type Discrete
Plating Gold
Max Current Rating 19A
Max Voltage Rating (AC) 600V
ELV Compliant
Wire Gauge 18-24 AWG
Operating Supply Voltage 600V
Contact Gender Male
Number of Contacts 1
Approval Agency UL
Contact Finish Gold
Current Rating 19A
Depth 4.19mm
Shielding Unshielded
Orientation Straight
Voltage - Rated 600V
Gender Male
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Pin
Termination Crimp
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Universal MATE-N-LOK
Published 1997
Packaging Tape & Reel (TR)
Physical
Underplate Material Nickel
Mount Cable
Contact Plating Gold
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 19 Weeks
