316836-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Contact SKT Crimp ST Cable Mount Strip
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.1848
≥1 USD $0.1848
≥10 USD $0.15576
≥100 USD $0.144672
≥500 USD $0.13728
≥1000 USD $0.129888
≥3000 USD $0.120912
Inventory: 204889
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Tab Thickness 640μm
Length 15.9mm
Height 3.45mm
Technical
Mating Tab Width 990.6μm
Pin or Socket Socket
Insulation Diameter 2.1 mm
Contact Termination Crimp
Sealable No
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 20 AWG
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Wire Gauge 20-22 AWG
Contact Resistance 20mOhm
Contact Finish Tin
Depth 2.5mm
Shielding Unshielded
Orientation Straight
Pitch 2.54mm
Gender Female
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Connector Type Connector, PCB, Signal, Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multi-Lock
Published 1999
Packaging Tape & Reel (TR)
Physical
Mount Cable
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 4 Weeks
