316040-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 14-16AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $2.1
Unit Price: USD $2.1032
≥1 USD $2.1032
≥10 USD $1.87088
≥100 USD $1.861376
≥500 USD $1.842368
≥1000 USD $1.680624
Inventory: 8394
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 23.4mm
Height 5.3mm
Technical
Pin or Socket Socket
Contact Retention With
Insulation Diameter 3.8 mm
Contact Termination Crimp
Contact Current Rating 30A
Sealable No
Wire/Cable Gauge 14 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 14-16 AWG
Operating Supply Voltage 630V
Contact Gender Female
Contact Finish Gold
Current Rating 30A
Depth 7.7mm
Shielding Unshielded
Orientation Straight
Gender Female
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Socket
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Dynamic D-5
Published 2006
Packaging Bulk
Physical
Underplate Material Nickel
Mount Cable
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 22 Weeks
