3-647485-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN RCPT HOODED CONTACT SL-156
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.21824
≥100 USD $0.198088
≥500 USD $0.142912
≥1000 USD $0.126632
≥3000 USD $0.112165
Inventory: 7374
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Bronze
Contact Plating Tin
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2007
Series SL-156
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Socket
Type Power
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Gender Female
Voltage - Rated 250V
Orientation Straight
Shielding Unshielded
Depth 3.94mm
Current Rating 10A
Contact Finish Tin
Contact Gender Female
Operating Supply Voltage 250V
Contact Style Standard
Contact Resistance 3mOhm
Wire Gauge 16 AWG
Wire/Cable Type Discrete
Wire/Cable Gauge 16 AWG
Sealable No
Contact Current Rating 10A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 2.84 mm
Pin or Socket Socket
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Plating Thickness 2.03μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
