282110-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
TE CONNECTIVITY 282110-1 Contact, SUPERSEAL 1.5 Series, Socket, Crimp, 15 AWG, Tin Plated Contacts
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.14168
≥100 USD $0.131648
≥500 USD $0.12496
≥1000 USD $0.118184
≥3000 USD $0.110035
Inventory: 75453
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Bronze, CuSn
Mount Cable
Number of Pins 1
Body Material Bronze
Technical
Packaging Tape & Reel (TR)
Published 1995
Series Superseal
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Connector, PCB, Signal
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Gender Receptacle
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 4.8mm
Current Rating 11A
Contact Finish Tin
Contact Gender Female
Wire Gauge 15-18 AWG
ELV Compliant
Connector Support Type CONNECTOR ACCESSORY
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 15 AWG
Wire/Cable Gauge 15 AWG
Sealable Yes
Contact Termination Crimp
Insulation Diameter 3.3 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Mating Tab Width 1.5mm
Cable Entry-Min 0.067 inch
Design Use POWER
Dimensions
Height 4.7mm
Length 16.5mm
Tab Thickness 800μm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Not Applicable
