2-87523-1 image
Favorite
2-87523-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKET 20-24AWG CRIMP GOLD
PDF
/
Inventory: 5368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 12.09mm

Technical

Pin or Socket Socket
Insulation Diameter 1.75 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 24 AWG
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 20-24 AWG
Operating Supply Voltage 250V
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Gold
Current Rating 3A
Shielding Unshielded
Orientation Straight
HTS Code 8536.90.40.00
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod IV
Published 2008
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Plating Nickel, Gold
Contact Material Bronze, Copper, Tin

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 weeks ago)
Factory Lead Time 13 Weeks
