2-87195-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 20-24AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.64328
≥100 USD $0.616704
≥500 USD $0.603504
≥1000 USD $0.57728
≥3000 USD $0.524832
Inventory: 6482
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 12.09mm
Height 2.03mm
Technical
Pin or Socket Socket
Insulation Diameter 1.75 mm
Contact Termination Crimp
Terminal and Terminal Block Type PUSH-ON TERMINAL
Contact Current Rating 3A
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
ELV Non-Compliant
Insulation Resistance 5GOhm
Wire Gauge 20-24 AWG
Contact Resistance 20mOhm
Operating Supply Voltage 250V
Contact Gender Female
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Gold
Current Rating 3A
Reach Compliance Code not_compliant
Depth 2.41mm
Shielding Unshielded
Orientation Straight
Pitch 2.54mm
HTS Code 8536.90.40.00
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod IV 1/2
Published 2006
Packaging Bulk
Physical
Mount Cable
Contact Material Bronze, Copper, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 5 Weeks
