181270-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONTACT RCPT CRIMP 26-22AWG GOLD
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9937
≥1 USD $0.9937
≥10 USD $0.8151
≥100 USD $0.7904
≥500 USD $0.76475
≥1000 USD $0.7391
Inventory: 1180
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness 16.0μin 0.41μm
Length 12.65mm
Technical
Cable Entry-Min 0.035 inch
Cable Entry-Max 0.061 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 1.55 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Connector Support Type CONNECTOR ACCESSORY
Plating Gold
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Contact Resistance 7mOhm
Operating Supply Voltage 40V
Contact Gender Female
Current Rating 3A
Depth 2.2mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Receptacle
Min Operating Temperature -40°C
Max Operating Temperature 80°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPMODU Mod II
Published 2007
Packaging Bulk
Physical
Mounting Style STRAIGHT
Body Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 22 hours ago)
Factory Lead Time 44 Weeks
