179594-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Power to the Board TAB 26-22AWG PRE-TIN
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.19272
≥100 USD $0.175384
≥500 USD $0.126544
≥1000 USD $0.11213
≥3000 USD $0.099308
Inventory: 1158
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 800 nm
Length 20.2mm
Height 3.7mm
Technical
Pin or Socket Tab
Insulation Diameter 2.0066 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 14A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Discrete
Max Current Rating 14A
ELV Compliant
Wire Gauge 22-26 AWG
Operating Supply Voltage 50V
Contact Finish Tin
Depth 3.5mm
Shielding Unshielded
Orientation Straight
Voltage - Rated 300V
Gender Male
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Type Power
Connector Type Tab
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Power Double Lock
Published 1997
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 14 Weeks
