175196-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 16-20AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.35464
≥100 USD $0.352704
≥500 USD $0.345488
≥1000 USD $0.29524
≥3000 USD $0.265725
Inventory: 77981
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 17.78mm
Technical
Pin or Socket Socket
Contact Retention With
Insulation Diameter 2.8 mm
Contact Termination Crimp
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 16-20 AWG
Operating Supply Voltage 250V
Contact Finish Gold
Current Rating 15A
Shielding Unshielded
Orientation Straight
Gender Female
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Socket
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Dynamic D-3
Published 1999
Packaging Tape & Reel (TR)
Physical
Underplate Material Nickel
Mount Cable
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 13 Weeks
