175151-4 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN SOCKET 22-26AWG CRIMP TIN
PDF
/
Inventory: 3806
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Plating Thickness 800 nm
Length 12.25mm

Technical

Rated Voltage(AC) 600V
Rated Voltage(DC) 600V
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.0066 mm
Contact Termination Crimp
Contact Current Rating 12A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Max Current Rating 12A
ELV Compliant
Wire Gauge 22-26 AWG
Operating Supply Voltage 50V
Contact Finish Tin
Current Rating 12A
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 300V
Gender Female
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Type Power
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Universal Power
Published 1999
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 13 Weeks
