1747419-2 image
Favorite
1747419-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Contact PIN Crimp ST Cable Mount Reel
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
≥10 USD $0.80872
≥100 USD $0.773344
≥500 USD $0.762432
≥1000 USD $0.666248
≥3000 USD $0.641344
Inventory: 38150
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 15.0μin 0.38μm
Length 21.7932mm

Technical

Pin or Socket Tab
Contact Retention With
Insulation Diameter 3.75 mm
Contact Termination Crimp
Contact Current Rating 24A
Wire/Cable Gauge 14 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 14-16 AWG
Operating Supply Voltage 600V
Contact Finish Gold
Current Rating 24A
Orientation Straight
Gender Male
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Type Power
Connector Type Tab
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Dynamic D-4200
Published 2005
Packaging Tape & Reel (TR)

Physical

Underplate Material Nickel
Mount Cable
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 19 Weeks
