1744201-1 image
Favorite
1744201-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Headers & Wire Housings CONTACT 16-20 AWG Reel of 4000
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.16192
≥100 USD $0.150304
≥500 USD $0.14256
≥1000 USD $0.134816
≥3000 USD $0.125523
Inventory: 173263
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Plating Thickness 800 nm
Contact Finish Thickness 19.7μin 0.50μm
Width 9.99mm
Length 2.79908mm
Height 3.9878mm

Technical

Pin or Socket Socket
Insulation Diameter 3 mm
Contact Termination Crimp
Terminal and Terminal Block Type PUSH-ON TERMINAL
Circuit Application Power
Contact Current Rating 12.3A
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
Max Current Rating 12.3A
ELV Compliant
Wire Gauge 16-20 AWG
Operating Supply Voltage 600V
Contact Gender Female
Contact Finish Tin
Depth 4mm
Shielding Unshielded
Orientation Straight
Pitch 3.96mm
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Economy Power II
Published 2011
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Material Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 16 Weeks
