171636-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 16-20AWG TIN CRIMP
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.132
≥1 USD $0.132
≥10 USD $0.10912
≥100 USD $0.101024
≥500 USD $0.09592
≥1000 USD $0.090728
≥3000 USD $0.08448
Inventory: 125886
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Plating Thickness 800 nm
Length 18mm
Height 4.95mm
Technical
Cable Entry-Min 0.079 inch
VDE Tested Yes
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 2.3876 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 7A
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 16 AWG
Number of Ports 1
Wire/Cable Type Discrete
Max Current Rating 7A
Max Voltage Rating (AC) 600V
Wire Gauge 16-20 AWG
Operating Supply Voltage 600V
Contact Gender Male
Approval Agency UL
Contact Finish Tin
Current Rating 9.5A
Depth 4.3mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -20°C
Max Operating Temperature 105°C
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Mini-Universal MATE-N-LOK
Published 1997
Packaging Tape & Reel (TR)
Physical
Contact Shape Square
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
