170429-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Headers & Wire Housings CONT 26-20 AWG
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
≥10 USD $0.11792
≥100 USD $0.10912
≥500 USD $0.103664
≥1000 USD $0.098032
≥3000 USD $0.091238
Inventory: 17788
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 380 nm
Length 18.1mm
Technical
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 1.91 mm
Contact Termination Crimp
Circuit Application Signal
Sealable No
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 20 AWG
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Wire Gauge 20-26 AWG
Contact Gender Male
Contact Finish Tin
Current Rating 2A
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Min Operating Temperature -20°C
Max Operating Temperature 95°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EI
Published 1999
Packaging Bulk
Physical
Mount Cable
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 22 Weeks
