1612334-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Headers & Wire Housings GRACE INERTIA CONNECTOR 3.5 RE
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.13992
≥100 USD $0.129888
≥500 USD $0.1232
≥1000 USD $0.116512
≥3000 USD $0.108486
Inventory: 876
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Length 13.9mm
Technical
Pin or Socket Socket
Insulation Diameter 2.0066 mm
Contact Termination Crimp
Circuit Application Power
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Discrete
Max Current Rating 4A
ELV Compliant
Wire Gauge 22-26 AWG
Operating Supply Voltage 300V
Contact Gender Female
Contact Finish Tin
Current Rating 7A
Shielding Shielded
Orientation Straight
Voltage - Rated 300V
Gender Female
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Connector Type Receptacle
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Grace Inertia, GIC
Published 2004
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 13 Weeks
