1586841-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Pin & Socket Connectors VAL-U-LOK SKT 16AWG BR SN LP
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.06336
≥100 USD $0.046306
≥500 USD $0.043877
≥1000 USD $0.036802
≥3000 USD $0.032349
Inventory: 36470
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 15.18mm
Height 4.5mm
Technical
VDE Tested No
Pin or Socket Socket
Insulation Diameter 3.0988 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 9A
Wire/Cable Gauge 16 AWG
Wire/Cable Type Discrete
Max Current Rating 9A
ELV Compliant
Wire Gauge 16 AWG
Operating Supply Voltage 600V
Contact Gender Female
Approval Agency UL
Contact Finish Tin
Current Rating 9A
Depth 3.6mm
Shielding Unshielded
Orientation Straight
Voltage - Rated 600V
Gender Female
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Connector Type Socket
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series VAL-U-LOK
Published 2008
Packaging Bulk
Physical
Mount Cable
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 16 Weeks
