1586316-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 22-26AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.0968
≥1 USD $0.0968
≥10 USD $0.08096
≥100 USD $0.074976
≥500 USD $0.07128
≥1000 USD $0.06732
≥3000 USD $0.062691
Inventory: 11661
Minimum: 1
-
+
Technical Details
Technical
Wire/Cable Gauge 26 AWG
Contact Current Rating 9A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 1.75 mm
Pin or Socket Pin
Assembly Item Name CONTACT
VDE Tested No
Cable Entry-Max 0.069 inch
Cable Entry-Min 0.047 inch
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 22 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 9A
ELV Compliant
Wire Gauge 22-26 AWG
Contact Resistance 10mOhm
Operating Supply Voltage 600V
Contact Gender Male
Approval Agency UL
Contact Finish Tin
Current Rating 9A
Depth 3.2mm
Shielding Unshielded
Orientation Straight
Pitch 4.2mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -40°C
Max Operating Temperature 221°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series VAL-U-LOK
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 16 Weeks
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Length 17.3mm
Height 3.4mm
