1241396-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Automotive Connectors MCP2.8 BU-KONT EDS
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2288
≥1 USD $0.2288
≥10 USD $0.19096
≥100 USD $0.17776
≥500 USD $0.168608
≥1000 USD $0.159456
≥3000 USD $0.148438
Inventory: 10545
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Tab Thickness 600μm
Length 19.5mm
Height 4.4mm
Technical
Mating Tab Width 2.794mm
Pin or Socket Socket
Insulation Diameter 2.9972 mm
Contact Termination Crimp
Sealable Yes
Wire Gauge (Min) 13 AWG
Wire Gauge (Max) 17 AWG
ELV Compliant
Wire Gauge 13-17 AWG
Contact Finish Tin
Depth 4.2mm
Shielding Unshielded
Orientation Straight
Gender Female
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Number of Positions 1
Type Stamped
Connector Type Connector, PCB, Signal, Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MCP
Published 2008
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Copper, Nickel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 15 Weeks
