106528-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN TERM SOCKET 22-26AWG T&R
PDF
/
Inventory: 4106
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Bronze
Mount Cable
Technical
Packaging Cut Tape (CT)
Published 2004
Series AMP-DUAC
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Power
Number of Positions 9
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Voltage - Rated 600V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 6.1mm
Orientation Straight
Shielding Unshielded
Depth 2.8mm
Current Rating 9A
Contact Finish Tin
Contact Gender Female
Operating Supply Voltage 600V
Wire Gauge 22-26 AWG
Max Current Rating 9A
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 26 AWG
Contact Current Rating 9A
Contact Termination Crimp
Insulation Diameter 1.75 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Dimensions
Height 2.9mm
Length 14.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
