104505-2 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Headers & Wire Housings MTE PIN 22-26 AWG
PDF
/
Inventory: 7555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Contact Finish Thickness 100.0μin 2.54μm
Length 20.62mm

Technical

Pin or Socket Pin
Insulation Diameter 1.37 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
ELV Non-Compliant
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Contact Resistance 12mOhm
Contact Style Crimp
Operating Supply Voltage 300V
Contact Gender Male
Approval Agency CSA
Voltage - Rated AC 300V
Contact Finish Tin-Lead
Current Rating 3A
Depth 1.9mm
Shielding Unshielded
Orientation Straight
Pitch 2.54mm
Gender Male
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Connector Type Pin
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU MTE
Published 2010
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Plating Lead, Nickel, Tin
Contact Material Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 4 Weeks
